The Systemizing Solution Supplier of Cable & Connector
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | LYCN |
| Certification: | UL/SGS/ROHS |
| Model Number: | 392S |
| Minimum Order Quantity: | 1000 PCS |
| Price: | Negotiation |
| Packaging Details: | Tray/Tube |
| Delivery Time: | 26-31 Days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 8000000pcs |
| Tail & Mounting Style: | DIP 180° | Withstand Voltage: | 600 V AV/Minute |
|---|---|---|---|
| Current Rating: | 2.0 AMP | Contact Resistance: | 20mΩ Max |
| Insulation Resistance: | 1000mΩ Min | Operation Temperature: | -40°C To +105°C |
| High Light: | 2.0mm Ejector Header,ROHS Ejector Header,DIP 10 Pin Header Connector |
||
2.00mm 10 Pin Ejector Header Connector 180°DIP With Brass Gold Flash
Product Application
The difference between the box header connectors and the ejector header connectors is that there are two more buckles on both sides. According to the demand, there are three commonly used specifications of the outer size of the ejector header connector: 1.27mm pitch, 2.0mm pitch, 2.54mm pitch.
The diameter of the square row of needles used varies according to the spacing. The bottom contact surface with PCB board can be designed for SMT SMT type or DIP direct insert 180 degrees.
Application: After welding the ejector header connector on the PCB board, connect the IDC cable with the corresponding specifications. It will form a new circuit connection with another circuit, which usually used to transmit control signals and weak currents.
Why choose us
1. Professional team
2. High-Quality Guarantee
3. Competitive Price
Specification
| 1. Contact Plating | Gold or Tin over Ni |
| 2. Insulator Material | PBT/PA6T/PA66/PA9T/LCP |
| 3. Pitch | 2.00 mm |
| 4. Latch |
Short Latch |
| 5. Color | Black |
| 6. Contact Material | Copper Alloy |
FAQ
1. When can I receive your quotation or reply?
Within 2 hours! If you submit quote request on our working time 9:00 a.m.to 18:00pm, we always can reply on Phone within 2 hours. You can get reply within 24 hours, if you asking on weekend or holiday. If you are urgent ,welcome to call us or talk online via Sales manager/Skype/ Wechat etc. Let's make waiting be short!!
2. Can you customize products for us?
Yes. we can! We are pleased to customize for you or design for you. The best support will be given by our professional equipment, technicians, skilled employees! If you provide drawing or samples for us, we can customize based on requirements. Let's achieve your ideas!!
3. Can you provide samples?
Yes. We provide free samples of regular products and you undertake freight cost. If it is customized item, we will charge for properly cost but reasonable proportion of sample fee will be refunded when you place an order for it! Our products will show you that it is worth to pay the freight!
