The Systemizing Solution Supplier of Cable & Connector
| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | LYCN |
| Certification: | ROHS/UL/SGS/REACH |
| Model Number: | 123XX0 |
| Minimum Order Quantity: | 1000 PCS |
| Price: | USD |
| Packaging Details: | TRAY/TUBE |
| Delivery Time: | 25-35 Days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 8000000Kpcs |
| Current Rating: | 3.0 AMP | Contact Resistance: | 10mΩ Max |
|---|---|---|---|
| Dielectric Strength: | Min 1000V RMS | Mechanical Life: | Min 500 Cycles |
| Sleeve: | Brass CuZn36Pb3(C36000) | Contact Clip(4 Finger): | BeCu(C17200) |
| High Light: | Machined Round PIN Header,Dual Row Round PIN Header,2.54 Mm Pitch Pin Header |
||
2.54mm Machined Pin Header Dual Row L=7.43mm Straight Height 3.0mm
Products Application
Wide Application: All of our products can be widely used in electronics, electrical appliances, instrument connection device, which mainly plays the role of a current or signal transmission.
Printed circuit board connectors are connecting systems used to transfer signals or power supplies from one PCB to another, or from another source built into the device to or from the PCB. Since PCBS are not hard-wired to each other, they can be assembled later in the production process, providing a simple design method for manufacturing.
The term PCB Connector refers to a basic multipin connection system, typically in a rectangular layout. A mating pair of PCB Connectors will either be for board-to-board or cable-to-board (wire-to-board). The board-to-board layouts can give a range of PCB connection orientations, all based on 90 degrees increments:
Why choose us
1. Timely delivery;
2. Technical support;
3. Samples for free;
Specification
| Insulator Material | PBT+30%GF(UL94V-0) |
| Contact Clip | Beryllium Copper (C17200) |
| Height | 3.0mm |
| Mating Pin | ∅0.64 To ∅0.90mm |
| Withdrawal Forces | 1 N Typ. |
| Insertion Forces | 2 N typ |
FAQ
1. How many kinds of packing can we provide?
We will choose the most suitable packing method to protect products well. Customers also could customize their packages.
2. What services can we provide?
Accepted Payment Currency: USD, EUR, JPY, CAD, AUD, HKD, CNY;
Accepted Payment Type: T/T, MoneyGram, Western Union;
Language Spoken: English, Chinese
3. What is your MOQ?
The Min. order quantity is 1,000pcs, the quantity depend on the item that customers need
